Schneider Electric LC1K09008F7

The Schneider Electric IEC Magnetic Contactor is a 4-pole, non-reversing device with a 110 V AC coil and screw clamp terminals. It is an IEC-style magnetic contactor (TeSys series) rated for switching power circuits within specified parameters. It has no auxiliary contacts and is listed under IEC Magnetic Contactors. This item is rated for use in IEC control panels with resistive and compatible load types within its specified ratings.- Coil voltage: 110 V AC – Poles: 4P; Main contact configuration: 2 NO + 2 NC – Reversing: Non-Reversing – Auxiliary contacts: No – Electrical connections: Screw clamp terminals – Series/Frame: TeSys – Utilisation category: AC-1 – Maximum voltage rating: Rated for operation up to 690 V AC; Insulation voltage as per specifications – Rated making capacity / Rated operational current: rated according to the specified current capacities under defined conditions – IP rating: IP22; Embedded surge suppressor: No – Enclosure: No Enclosure -> open device without enclosure, as specified – Ambient storage temperature: -50 to 80°C – Operating altitude: Suitable for operation at altitudes up to 2000 meters within environmental limits – Dimensions: Height 2.28 in; Width 1.77 in; Depth 2.24 in – Weight: 0.18 kg – Mounting: DIN Rail, Plate (Mounting Support: Rail; Plate) – Impedance: 3 mΩ – Inrush VA: 30 VA; Hold-in power: 4.5 VA; Watts loss: 1.3 W – Impulse withstand voltage: Tested for impulse withstand voltage of up to 8 kV in accordance with standards – Short-time withstand current: up to 90 A (1 s), 85 A (5 s), 80 A (10 s), 60 A (30 s), 45 A (1 min), 40 A (3 min), 20 A (15 min) for power circuit – Operating speed: 3600 cycles per hour – Overvoltage category: CAT III – Vibration/shock: 4 G (Closed), 2 G (Open); Shock: up to 15 G (various axes) – Certifications: CB Scheme; CCC; UL; CSA; EAC; CE; UKCA – Rated making/short-time ratings and standards reflect IEC 60947-4-1/60947-5-1 scope and related tests.
